th400; help
Topic Started: Apr 29 2010, 09:55 PM (274 Views)
Deleted User
Deleted User

Hey all haven't brleen here in a while. Well I busted my tranny and now I got my self a th400. And I hear talk that I need a kick down switch any one have experience with this
Quote Post Goto Top

Ashley
Member Avatar
NYTHIRDGEN's First Lady
hmm, not sure

btw is it new, rebuilt or just new to you

1988 IROC-Z 350 5.7 liter TPI L98, 700r4, 3:43 posi disc, MSD 6al Ignition, CompCam 260 with 1.6RRs, Edelbrock shorty headers, Flowmaster 40 series 3" duals & Custom Y-Pipe, TCI 2800 RPM Torque converter, AutoMeter gauges, 15in Weld Racing wheels

Que linda me la traiga Cuba, La reina de la Mar Caribe, Quiero solo visitarla alli, Y que triste que no puedo vaya, O va, o va
Offline Profile Quote Post Goto Top

gp90gta
Member Avatar
The Professor
A TH400 is a vacuum operated kick down, what that means is that it does not use a tv (throtle valve) cable or what most people call a kickdown cable so to answer your question no you do not need a switch just a vacuum hose from the intake to the trans
Posted Image
1990 GTA, 350, AFR195's, TPIS Miniram, Dyno Don headers, Custom bumpstick by Bullet cams, 36lbs injectors, Spohn SFC's, Custom tune by me.
Offline Profile Quote Post Goto Top

charged355
Member Avatar
Nythirdgen Founder
You need a differ crossmember and a torque arm mount kit for a th400 and might need a differ lenght driveshaft pending on what tail is on that tranny, and put a manual valvebody in it so no need for anything but a shifter
Posted Image

Custom Forged 355 / Solid roller cam/valvetrain / Victor Jr heads / Hurricane Intake/ Accufab 1250cfm Throttle body / MegaSquirt 3 Engine Managment/ 1000cc SouthBay Injectors/ 7.6:1 CR / 4" Custom Single Exhaust / 4000 Circle D Stall/ CK Performance Billet 4L80 FMVB Trans Brake / 3" Chromoly Driveshaft / Full UMI Tubular Rear Suspension / Moser/Strange 9" / 4:11 gears Detroit Locker / Sumped LS1 gas tank / A1000 Fuel pump / A1000 FPR / Paxton Fuel filter / -10 Fuel line -8 return / Borg Warner S475 Turbo @10psi/ JGS 50mm WG & 56mm BOV / PA Racing Complete Tubular Front End Kit With Coilovers / Full Autometer Dash / Custom Black Suade Guts / Built by yours truly/ Tuned by George the EFI whiz

http://www.youtube.com/channel/UCnxlPhzRElZYM5YE-n2NRUw
Offline Profile Quote Post Goto Top

Deleted User
Deleted User

It was rebuilt in Connecticut and it is new to me the tranny has a vacuum line and a single cable coming out of it and the guy at the tranny shop told me about a actual switch that mounts to ur intake manifold and is connected to the carb linkage to control shifting. Soo I'm confused? And I got Tue new cross member and the drive shaft is the same just new yokes

O. And its going in with a brand new 400ci 6.6 liter motor
Quote Post Goto Top

84 z28
Member Avatar
Member
There is an electronic kickdown switch in the th400. Its usally mounted on the throttle pedal. Everything else is done by vavccum. A th350 would of had a cable going from the trans to the carb throttle linkage.
Posted Image
Offline Profile Quote Post Goto Top

Deleted User
Deleted User

ok so i ordered the cross member here
http://www.hawksthirdgenparts.com/camarofirebirdspohn82-92turbo350transmissioncrossmember-1-1-1.aspx

and when i was at the shop the dude said that if i have that cable, witch looks like a regular wire i need the kick down, so i dont know what to do, what would that wire connect to when i put in the tranny,

and were on the intake manifold do i put the vacuum, i have the edlebrock performer intake, how about the carb, can i put it there?

and if there is any one in the queens area that knows i live in middle village, call me at 9175844883 if you wanna see for your self.
Quote Post Goto Top
